| Part# | Ball Diameter and Maximum GTW/ TW | Drop | Rise | Length | Mount Finish | ||||||||||
| 2" | 2-5/16" | ||||||||||||||
| AD4978P | 8000/800 lbs. | 12500/1250 lbs. | 4" | 4" | 9-7/8" | Polishing | |||||||||
| AD4978P | 8000/800 lbs. | 12500/1250 lbs. | 4" | 4" | 9-7/8" | Gloss black | |||||||||
| AD6978P | 8000/800 lbs. | 12500/1250 lbs. | 6" | 6" | 9-7/8" | Polishing | |||||||||
| AD6978P | 8000/800 lbs. | 12500/1250 lbs. | 6" | 6" | 9-7/8" | Gloss black | |||||||||
| AD8978P | 8000/800 lbs. | 12500/1250 lbs. | 8" | 8" | 9-7/8" | Gloss black | |||||||||
| AD10978P | 8000/800 lbs. | 12500/1250 lbs. | 10" | 10" | 9-7/8" | Polishing | |||||||||
| AD10978G | 8000/800 lbs. | 12500/1250 lbs. | 10" | 10" | 9-7/8" | Gloss black | |||||||||
| AD6838P* | 8000/800 lbs. | 5000/500 lbs. | 6" | 6" | 8-3/8" | Polishing | |||||||||
| AD6838G* | 8000/800 lbs. | 5000/500 lbs. | 6" | 6" | 8-3/8" | Gloss black | |||||||||
